6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box
6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box 6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box 6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box 6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box 6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box

Большие изображения :  6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box

Подробная информация о продукте:
Место происхождения: ВИВИА Н
Фирменное наименование: BEST
Сертификация: CE
Оплата и доставка Условия:
Количество мин заказа: 1 комплект
Цена: USD24000--30000
Время доставки: 50 рабочих дней
Условия оплаты: Л/К, Т/Т
Поставка способности: 20 комплектов/месяц

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box

описание
Напряжение: 380 В, 50 Гц, 3 фазы Использовать: C&Z
Система управления: PLC (импортный бренд) Материал ролика: CR12
Имя: Толщина 6 мм, оцинкованная, L-образная форма, коробка передач машины для формовки крена Цвет: синь или согласно потребности клиента
Выделить:

6mm galvanized L shape roll forming machine

,

L shape roll forming machine gear box

,

purlin roll forming machine with gear box

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box  0


6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box Technical parameters:


Raw material
material spec sheet, galvanized steel sheet, aluminum sheet
thickness of coil sheet 3-6mm
Machine details
roller material High grade Gcr14 forged steel with 0.05mm hard chrome plating
shaft material High grade NO. 45 carbon wrought steel
cutting blade Cr12 mould steel with quenched treatment
diameter of shaft 1000mm
forming steps 10 rows
productivity 8m/min
hydraulic station power 22 KW
hydraulic pressure 10-12MPa
controlling system famous PLC computer control
material of cutting table Cr 12 mould steel with quenched treatment
appearance size 7500mm*1150mm*1510mm
hydraulic oil 40# hydraulic oil
Electric tension 380V 50 Hz 3 Phase or as your requirements

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box  1

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box Device Configuration

No
number
(1) Manual decoiler 1 set
(2) Guiding device 1 set
(3) Main roll forming machine 1 set
(4) Hydraulic cutting device 1 set
(5) PLC electric control system 1 set
(6) Hydraulic driving system 1 set
(7) Special tools and parts 1 set


Characteristic


  • Adopt touch screen control box through the man-machine interface, convenient operation, good appearance, consistent with the whole equipment.
  • The main components will stable performance, good reputation, global procurement.
  • Using a number of control technology, automation degree is high.
  • Encoder count, length accurately.


3. Machine picture

4. Installation and training:

A. If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also trainyour workers/technician face to face.

B. Without visiting, we will send you user manual and video to teach you to install and operate.

C. If buyer needs our technician to go to your local factory, please arrange board and lodging andother necessary things.


6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box  Our Machine Advantage

1. Good quality: We have a professional designer and experienced engineer team.And the raw material and accessories we use are good.

2. Good service: we provide the technical support for whole life of our machines.

3. Guarantee period: within one year since the date of finishing commissioning. The guarantee covers all the electric, mechanic and hydraulic parts in the line except for the easy-worn parts.

4. Easy operation:All machine cotrolled by PLC computer controlling systerm.

5. Elegant apperance:Protect the machine from rust and the painted colour can be customized

6. Reasonable price:We offer the best price in our industry.

6. FAQ

1. Q: Are you manufacturer or trading company?
A: We are manufacture
2. Q:What info you need before you make the proposal?
A:The pipe diameter and thickness range which you need or the profile drawings, material information, your special requirements.
3. Q: what is the MOQ?
A: One set
4. Q: Do you provide installing and debugging overseas?
A: Overseas machine install and worker training services are optional

6mm Thickness Galvanized L Shape Roll Forming Machine Gear Box  2
